PRODUCTS TIVAL SENSORS

Perbunan diaphragm

Pressure connector G 3/8“ Female thread, ALSi 12

Pressure range from 0,11...32 bar

Change-over contact

Pressure switch FF 4-... DAH(G)

Perbunan diaphragm

Pressure connector G 3/8“ Female thread and plastic pressure connector

Pressure range from 0,11...16 bar

Change-over contact

Pressure switch FF 4-... DAY

Stainless steel bellows

Pressure connector: G (G 1/4“ Female thread, stainless steel)

Pressure range from 1...30 bar

Change-over contact

Media temperature max. +200° C

Pressure switch FF 4-... AAG

Plastic plunger

Pressure connector: H (G 3/8“ Female thread, DIN 1725/2), stainless steel

Pressure range from 8...250 bar

Change-over contact

Pressure switch FF 4-... PAH

Perbunan diaphragm

Pressure connector G 3/8“ Female thread, ALSi 12

Pressure range from 0,11...32 bar

Manual reset

Pressure switch FF 4-.. DRH/DDH

Pressure switch with UL / CSA- approval

Pressure range from 3...870 psi

Change-over contact

Pressure switch FF 444

For intrinsically safe circuits

Protection class: IM2 Ex ia IMb for mining applications

Protection class: II 2G Ex ia IIC T6 Gb for chemical applications

Change-over contact

Pressure switch FF 4 ATEX

Approved for shipbuilding applications by DNV GL

Pressure switch 2 ... 32 bar, with perbunan diaphragm

High pressure switch 4 ... 60 bar, with plastic plunger

Change-over contact

Pressure switch FF 4 GL

For firefighting equipment, VdS-approval

Perbunan diaphragm

Pressure connector: I (G 1/2“ Female thread, DIN 1725/2), ALSi 12

Pressure range: 2, 10, 16 bar

Pressure switch FF 4 VdS

Perbunan diaphragm, standard enclosure, G 3/8" female, polyamid

Pressure switch with stainless steel bellows, R 1/4" male, stainless-steel.

Pressure range: 0,2 ...21 bar (Perbunan diaphragm)

Pressure range: -0,4...40 bar (stainless steel)

2 change-over contacts

Pressure switch FF 142

Brass / bronze bellows

Pressure connection: 1/4" male, steel

Presure range: -0,5...31 bar

1 Change-over contact

UL / CSA- approval

Mechanical Pressure switch PS1

ure pressure switch, OEM- Type

Custommade styles

Pressure range: -0,6... 43 bar

Manual reset as option

UL / CSA- approval

Mechanical Pressure switch PS3

NBR- or silicone diaphragm

Pressure range: 10...1000 mbar

High pressure resistance

Change- over contact



Pressure switch FF 501

Flush mounted FKM diaphragm

High-rated over-pressure safety

Pressure connection: stainless steel, 3/4" male

Change-over contact

Pressure switch FF 603

Vacuum switch

High-rated over-pressure safety

Pressure connection: 1/4" male, brass

Change- over contact

Pressure switch FF 701

High pressure switch up to 400 bar

Pressure connection: 1/4" famale

High-rated over-pressure safety

Diaphragm- or piston-type pressure switch

Change-over contact

Pressure switch FF 902

Direct switching action of AC electrical motors

2- and 3-pole pressure switch

Optional unloader valve equipped

Perbunan-diaphragm

Mechanical Pressure switch PM/PT

Electronic pump control of 2-phase pumps

Pressure switch and dry running protection in one unit

Automatical restart after "dry running" identify

Optional cable with molded plug and cable with molded coupling

Electronic Pump control EPS-MT

Pressure switch with rotatable 14-segment LED display

Measuring ranges from -1 ... 0 bar to 0 ... +600 bar

Measurement of gauge pressure, absolute pressure and vacuum ranges

Up to 2 switching outputs and 1 analog output possible

Optionally available with IO-Link

Electronic pressure switch TST-PSD 30

Electronic pressure switch in transmitter design

Measuring ranges from 0 ... +0,6 bar to 0 … +2000 bar

NPN or PNP switching output with adjustable switching delay

Media temperature -40 … +125 °C

Compact and robust stainless steel housing

Electronic pressure switch TST-DS5

Measuring ranges from -1 ... 0 bar to 0 ... +1000 bar

Output signal 4 ... 20 mA (2- or 3-wire) or 0 ... 10 V (3-wire)

Dry stainless steel measuring cell and compact stainless steel housing

Media temperature -40 … +125 °C

Available as relative pressure or absolute pressure transmitter

Pressure transmitter TST 10... / 20...

Approved for shipbuilding applications by Germanischer Lloyd
Certified acc. Germanischer Lloyd GL Directive, Chapter 2, Edition 2012
Measuring ranges from -1 ... 0 bar to 0 … +2000 bar
Output signal 4 ... 20 mA (2-wire)
Dry stainless steel measuring cell and compact stainless steel housing

Pressure transmitter TST 16.0 GL

Measuring ranges from > 0 ... +1000 bar to 0 … +4000 bar

High pressure connection with double seal cone

Output signal 4 ... 20 mA (2- or 3-wire) or 0 ... 10 V (3-wire)

Suitable for aggressive liquid or gaseous media

Media temperature -40 … +125 °C

High pressure transmitter TST-SMH

Measuring ranges from 0 ... +10 mbar to 0 … +40 bar

Output signal 4 ... 20 mA (2- or 3-wire) or 0 ... 10 V (3-wire)

Media temperature -40 … +85 °C

Compact and robust stainless steel housing

High reliability

Pressure transmitter TST-SiAl

<p>Measuring ranges from 0 ... +100 mbar to 0 ... +2.5 bar</p> <p>Output signal 4 ... 20 mA (2- or 3-wire) or 0 ... 10 V (3-wire)</p> <p>Media temperature -20 ... +80 °C</p> <p>Compact and robust stainless steel housing</p> <p>High reliability</p>

Pressure transmitter TST-CIT

Intrinsically safe pressure transmitter with ATEX approval

Ex approval for Zone 0: II 1G Ex ia IIB T4 or II 1G Ex ia IIC T4

Ex approval for Zone 1: II 2G Ex ia IIC T4

IECEx approval acc. Ex ia IIB T4 Ga or Ex ia IIC T4 Gb (Ga with M12x1)

Measuring ranges from +10 ... +600 mbar to 0 … +1000 bar

Output signal 4 … 20 mA

ATEX-Pressure transmitter TST-SMX 2

Front flush G 1/2 "process connection with double seal

Front flush diaphragm made of stainless steel 1.4404 (316L)

Measuring ranges from 0 ... +250 mbar to 0 ... +40 bar

Output signal 4 ... 20 mA (2- or 3-wire) or 0 ... 10 V (3-wire)

Quick and easy zero point calibration for relative pressure sensors

Pressure transmitter TST-SPT-F

For use with higher temperature requirements and in environments with high thermal loads

For media temperatures from -40 ... +180 °C

Cooling section made of stainless steel

Measuring ranges from 0 ... +1 bar to 0 ... +1000 bar

High-temperature pressure transmitter TST-SKL

Front flush G 1/2 "process connection, type E with FKM seal

Front flush diaphragm made of stainless steel 1.4404 (316L)

Measuring ranges from 0 ... +100 mbar to 0 ... +60 bar

Output signal 4 ... 20 mA (2- or 3-wire) or 0 ... 10 V (3-wire)

Quick and easy zero point calibration for relative pressure sensors

Pressure transmitter TST-CIT-F

ecial version for mobile hydraulics with high vibration and EMC resistance

Increased shock resistance of 1000 g according to IEC 68-2-32

Increased vibration resistance of 30 g acc. to IEC 68-2-6 and IEC 68-2-36

Measuring ranges from 0 ... +4 bar to 0 … +4000 bar

Optionally with load-dump protection module

Pressure transmitter TST-SMO

Parallel and independent measurement of pressure and temperature

Temperature measurement with internal temperature sensor

Media temperature -40 ... +125 °C, Temp. measuring range -50 ... +150 °C

Pressure measuring ranges from 0 ... +1 bar to 0 … +1000 bar

Fully welded stainless steel measuring cell and stainless steel housing

Pressure and temperature transmitter TST-TPSI

Parallel and independent measurement of pressure and temperature

Temperature measurement with external temperature probe

Media temperature -40 ... +125 °C, Temp. measuring range configurable

Pressure measuring ranges from 0 ... +4 bar to 0 … +600 bar

4 ... 20 mA analogue output signals for pressure and temperature

Pressure and temperature transmitter TST-TPSE

Integrated CANopen interface according to Standard 2.0 A (optional B) with data rates up to 1 Mbit/s

Measuring ranges from 0 ... +1 bar to 0 … +1000 bar

Dry stainless steel measuring cell and compact stainless steel housing

Media temperature -40 … +125 °C

Pressure transmitter TST-SMC

Measuring ranges from 0 ... +40 mbar to 0 ... +250 bar

Output signal 4 ... 20 mA (2-wire) or 0 ... 10 V DC (3-wire)

Dry ceramic measuring cell and robust stainless steel housing

Vacuum-proof and high overload resistance

Total measurement error ≤ 0.2 % FS

Pressure transmitter TST-K121

Measuring ranges from -1 ... 0 bar to 0 ... +20 bar

Also as intrinsically safe version with ATEX-approval

Frontflush, dry ceramic measuring cell

Vacuum-proof and high overload resistance

Total measurement error ≤ 0.3 % FS

Pressure transmitter TST-K20

Differential pressure transmitter for air and non-agressive gases

With 4 ... 20 mA or 0 ... 10 V DC analog output

Also available with switching output (transistor or relay)

Switchable measuring ranges via bridges in the device

Available with and without display

Differential pressure transmitter TST-DD 10.0 / 20.0

Pressure range stages from +0,4 ... +1000 bar

Optionally differential pressure from 1:2 to 1:15 of nominal pressure value

Overpressure safety 1,2 x nominal value

Wetted parts made of stainless steel

Available with and without display

Differential pressure transmitter TST-DDM 10.0 / 20.0

Metallic measuring cell with 1.4404 stainless steel diaphragms

Differential pressure measuring (ΔP) from 0 ... +50 mbar to 0 ... +25 bar

Maximum static pressure & one-sided overload resistance of +40 bar

Analog output 4 ... 20 mA, 2-wire

Total measurement error ≤ 0,2 % FS

Differential pressure transmitter TST-DD 40

Metallic measuring cell with 1.4404 stainless steel diaphragms

Differential pressure measuring (ΔP) from 0 ... +50 mbar to 0 ... +25 bar

Max. static pressure & one-sided overload resistance of +100 / +250 bar

Analog output 4 ... 20 mA, 2-wire

Total measurement error ≤ 0,2 % FS

Differential pressure transmitter TST-DD 41

63 mm stainless steel housing, process connection on the back

Dry ceramic measuring cell

Analog output and one PNP transistor switching output

Measuring ranges from 0 ... +250 mbar to 0 ... +250 bar

3-digit LED display with 14 mm digit height

Digital contact gauge TST-PM 63

82 mm stainless steel housing, process connection on housing bottom

Dry ceramic measuring cell

Analog output and one or two PNP transistor switching outputs

Measuring ranges from 0 ...+25 mbar to 0... +250 bar

3-digit LED display with 14 mm digit height

Digital contact gauge TST-PM 82

Ultrasonic level sensor for continuous level measurement

Measuring ranges from 0,1 … 1 m to 0,5 … 20 m

PVDF housing, IP 65

Status display via two LEDs directly on the sensor

Also as intrinsically safe version with ATEX-approval

Ultrasonic level sensor TS-UNS

Stainless steel housing 1.4404, IP 68, diameter 40 mm

Measuring ranges from 0 ... 40 mbar to 0 ... +60 bar

Total measurement error ≤ 0.2 % FS

On request with PP or PVDF plastic housing

Optionally as intrinsically safe version with ATEX‑approval

Level probe TST-HD 133

Stainless steel housing 1.4404, IP 68, diameter 22 mm

Measuing ranges from 0 ... +100 mbar to 0 ... +20 bar

Total measurement error ≤ 0,25 % FS

Integrated overvoltage protection

Optionally as intrinsically safe version with ATEX approval

Level probe TST-HD 135

Stainless steel housing 1.4404, IP 68, diameter 22 mm

Measuring ranges from 0 ... +100 mbar to 0 ... +20 bar

Total measurement error < 0,3 % FS

Optionally integrated Pt 100 sensor for temperature measurement

Optionally as intrinsically safe version with ATEX approval

Level probe TST-HD 135K

Stainless steel housing 1.4404, IP 68, diameter 22 mm

Measuing ranges from 0 ... +250 mbar to 0 ... +20 bar

Total measurement error ≤ 0,5 % FS

Optionally integrated Pt 100 sensor for temperature measurement

With screwed POM protective cap

Level probe TST-HD 137

Hydrostatic pressure sensor for use in rainwater

Brass housing, IP68, diameter 22 mm

Measuring range 0 ... +250 mbar, 20 meters PVC suspension cable

Total measurement error ≤ 1,0 % FS

Level probe TST-TRA 250 / 20

Guided radar with measuring probe in different versions

Continuous level measurement and simultaneous level detection

Suitable for liquids and powdery solids

No influences due to fittings in the tank

Fast reaction time of 0.5 sec.

TDR level sensor TS-KFA 2

Electronic level switch with rotatable 14-segment LED display

Measuring ranges 189, 309, 349, 459, 669 mm

Easy menu navigation according to the VDMA standard

User-friendly 3-button operation

Up to 2 switching outputs and 1 analog output possible

Electronic level switch TS-LSD 30

High measuring accuracy of liquid levels

Joint lever capable of almost 180˚ measuring deflection

Suitable for measurement in pressurized holding tanks

Simultaneous switching and measuring

Joint lever transmitter TS-KNG

Continuous level monitoring with reed contact chain

Standpipe made of stainless steel (1.4571)

Pipe length freely selectable in the range of 100 ... 1900 mm

Float made of NBR

Output: variable resistance value, optionally 4 ... 20 mA

Float switch TS-RFK, Level probe with reed contacts

Alignment-free initial operation

Product-independent switching point

Very high reproducibility

Wear- and maintenance-free

Merest installation dimension

Vibration limit switch TS-SG 51

Filling and draining of tanks and reservoirs

Monitoring of wells

Dry-running protection

Level controller TS-NW3

Monitoring of non-flammable electrical conductive liquids

Filling and draining of tanks and reservoirs

Well monitoring

Dry-running protection

Level controller mounted in housing TS-003 W

Single pole immersion electrode

Stainless steel core

Polypropylene protective cover

Immersion electrode EL-V

Single pole immersion electrode

Stainless steel core

Polyethylene protective cover

Immersion electrode EL-1

Level limit monitoring for liquids in non-conductive plastic and glass vessels

Flexible polyurethane-housing, IP 67

Simple mounting and fast sensor configuration

Capacitive level limit switch TS-KGS

Level limit monitoring for liquids in non-conductive plastic and glass vessels

Polypropylen-housing, IP67

Simple mounting and fast sensor configuration

Capacitive level limit switch TS-KGS-25

Available for 2-wire or 3-wire level limit switches such as TS-KGS-25

Two independent relay outputs

Preconfigured program for pump control

Integrated power supply unit to supply the connected sensors with 12 V DC

Level limit controller TS-KGS-W1222

Level limit float switch with two switching points

Stainless steel Guide tube

Different types of floats available

Fill-level probe length 100 … 1900 mm

Level limit Float switch TS-RFS

Liquid level probe/sensor, reed-contact equipped

Float pipe available in a choice of materials, PVC, PP, PVDF or stainless steel

Up to a maximum of 5 reed-modules per application

Float lever equipped with permanent magnet

Floater switch TS-MPS

Monitoring and control of 1 to 5 liquid levels

3 operating modes: filling, emptying and level monitoring

Number of reed-modules adjustable to scale

Level control TS-NIA

For use in potable and waste water

Sidewall mounting in tanks

Inside or outside mounting

Float switches LS 303-51 and 803-51

Level limit float switch with single switching point

Compact design, right-angled construction

Configurable as NO or NC contact

Output: reed contact

Level limit Float switch TS-NSR

Hollow body, ball and microswitch equipped

Polypropylene (PP) housing

Adaptor plug type available

Float switch OPT for liquid level control

Ultrasonic level sensor for level limit monitoring

Measuring ranges from 0,1 … 1 m to 0,5 … 20 m

PVDF housing, IP 65

Status display via two LEDs directly on the sensor

Ultrasonic level sensor TS-UNS (Switching output)

Measuring ranges: 1 ... 80 ltr. / Min.

Optionally with small quantity measuring range: 0.4 ... 6 Ltr. / Min.

Analog outputs (mA, V, frequency)

Compact design, low pressure loss and high overload safety

Very short reaction time

Flow Sensor TS-FM, dynamic, analog

Calorimetric flow sensor in 12 mm stainless steel housing

Applicable in numerous nominal pipe sizes

Measuring range: liquids with 2 ... 150 cm/s or 3 ... 300 cm/s

Output signal proportional to the flow velocity

0/4 ... 20 mA or 0/2 ... 10 V DC analogue, frequency or switching output

Flow Sensor TS-FK 12

Stainless steel housing (1.4301)

Plug connector acc. to DIN EN 175301-803 form A

G 1/4“ process connection as standard

Immersion depths selectable

Temperature transmitter TS-TT

Rotatable, easily readable and rugged 14-segment LED display

Temperature range from -20 … +80º C

Simple menu navigation (acc. to VDMA standards)

User-friendly 3-button control

Up to two switching outputs and one analog output possible

Temperature switch TS-TSD 30

Pluggable, screwable, with neck pipe

Pt 100 accc. To DIN EN 60751 cl.B

Also available as thermocouple element

Resistance thermometer EWT

Certified for zone 1 and 2 usage

GL-approval 13989-15HH

Pt100 acc. to DIN EN 60751

Resistance thermometer BR

Ex II 2G Ex ia IIC T6-T2

GL-approval 13989-15HH

Pt 100 according to DIN EN 60751 class B

Resistance thermometer EWTS

Bend protection spring equipped

Pt 100 according to DIN EN 60751 class B

3- and 4-conductor connection provided

Resistance thermometer KWT Screw-in

GL-approval 13989-15HH

ATEX- version also available

Pt 100 according to DIN EN 60751 Kl. B

Resistance thermometer KWT Insertion

Multifunction panel meter for panel mounting

Integrated, galvanically isolated transmitter supply

Optionally with minimum and maximum value memory, if equipped with 2nd measuring input, display of differential, average value, larger or smaller measured value

Easy installation and operation

Multifunction panel meter TS-S 9648

Multifunction display for standard signals in IP65 field housing

Optionally with 2 alarm outputs (relay change-over contacts) and/or one analog output (0/4 ... 20 mA, 0/2 ... 10 V DC)

Integrated 24 V transmitter supply

Easy installation and operation via 3 control buttons

Multifunction display TS-S 110

Digital display for DIN rail mounting with configurable measuring range

Input for standard signals (0/4 ... 20 mA, 0/2 ... 10 V DC)

Integrated transmitter supply 24 V, max. 30 mA

Optionally with up to 4 alarm outputs (relay changer) and/or one analogue output (0/4 ... 20 mA, 0/2 ... 10 V DC)

Digital display TS-MR 50

Plug-in display for 4 ... 20 mA sensors with angled plug according to DIN EN 175301-803 / A

LCD display, 30 x 15 mm

Display range -1999 ... 9999 digits

Display area and decimal point programmable

Plug-on display TST-LCD

Input for switching contacts, Namur initiators according to DIN EN 60947-5-6 or optocouplers

With 230 V AC or 24 V DC supply voltage

Available as 1- or 2-channel version

Switchable monitoring of the input circuit for wire break and short circuit

Isolating switching repeater TS-500 Ex

1- or 2-channel isolation switching amplifier for digital switching signals

Safe galvanic isolation between input / output / supply voltage

Functional safety up to SIL2 acc. EN61508, also available in Ex version

Supply voltage 24 V DC or via wide-range power supply

Available as 1- or 2-channel version

Isolating switching repeater TS125 / TS225

Universal Ex seperator with internal supply for 2- and 3-wire sensors

Universal inputs 0/4 ... 20 mA and 0/2 ... 10 V DC, intrinsically safe acc. ATEX II (1) G [Ex ia] IIC and ATEX II (1) D [Ex iaD]

Outputs 0/4 ... 20 mA simultaneously 0/2 ... 10 V DC

Galvanic isolation between input / output / supply voltage

22.5 mm standard housing for DIN rail mounting

Universal isolation amplifier TV 500-Ex and Universal Ex seperator ST 500-Ex

Single-channel isolation amplifier for safe galvanic isolation between input / output / supply voltage

Input for standard signals (0/4 ... 20 mA, 0/2 ... 10 V DC)

As ST125 with integrated supply for 2- and 3-wire sensors

Functional safety up to SIL2 acc. EN61508, also as Ex version

Configuration via front DIP switches

Universal isolation amplifier TV125M / ST125M

Safety barrier to prevent the ignitability of circuits within an explosive area

Two stages of pulse-tested zener/on-state diodes per channel, for limiting voltage and current in hazardous areas

All models have 'ia' certification for all zones and 'IIC' for all explosive atmospheres

Zener diode barrier MTL 7787+

Transducer for platinum temperature sensors for DIN rail mounting

Input for Pt100 or Pt1000 in 2- or 3-wire set-up

Temperature measuring range according to individual specification

Output signal 0/4 ... 20 mA and simultaneously 0/2 ... 10 V DC

Supply voltage 230 V AC or 24 V DC

Temperature measuring transducer MU500L

Universal input for Pt100, Pt1000, NTC, thermocouples and resistance measurements

4 ... 20 mA analog output

Configuration of the measuring range via front DIP switches

Zero point and final value can be set via trim potentiometer

12.5 mm housing for DIN rail mounting

Temperature measuring transducer MU125

Soft start and soft stop

Current limit

Build-in motor protection

Build-in bypass

Start/stop by dry contact

Analog soft starter ESA 3000-A

Superior starting and stopping characteristics

Comprehensive motor protection package

Complete line 8 ... 3 500 A, 230 ... 1000 V

Heavy duty design

RS 485 Modbus/Profi bus

Digital soft starter ESA 3000-D

Adjustable braking time

DIN rail mounting (Standard 10 A, option 17 ... 58 A

)Auto Mode – DC - injection

Preventing mechanical wear

DC injection brake EMB 4000
